WLAN - 802.11 Chipset Power Supply
Implementation Using the ISL6413
PRELIMINARY
Application Note
October 2003
AN1081.1
Author: Manisha Pandya
ISL6413 Triple Output Regulator with
Single Synchronous Buck and Dual LDO
The ISL6413 is a highly integrated triple output regulator
which provides a single chip solution for wireless chipset
power management. The device integrates a high efficiency
synchronous buck regulator with two ultra low noise LDO
regulators and a RESET. It accepts an input voltage range of
3.0V to 3.6V and provides three regulated output voltages:
1.8V (PWM), 2.84V (LDO1), and another ultra low noise
2.84V (LDO2). The PWM output maintains regulator down to
2.7V input voltage.
Quick Start Evaluation
The evaluation board is shipped “ready to use” right from the
box. The board accepts a 3.3V input from a standard power
supply. The output can be exercised through the use of an
external load.
There are posts available on the board for introducing power,
for drawing current from the regulated output, and also for
testing other functions like RESET, SYNC, Power Good and
Shutdown.
Recommended Test Equipment
The PWM regulator is a current mode control synchronous
buck regulator with integrated N- and P- channel power
MOSFETs. It’s output is pre-set to 1.8V for the BBP/MAC
core supply. Synchronous rectification with internal
MOSFETs achieves >92% efficiency. The operating
?
?
?
?
A 3.3V, 2A capable power supply
An electronic load 3 channels
A four-channel oscilloscope
Precision digital multimeters
frequency is typically 750kHz allowing the use of smaller
inductor and capacitor values. The device can be
synchronized to an external clock signal in the range of
500kHz to 1MHz. The PG_PWM output indicates any loss of
regulation on the PWM output.
The ISL6413 also has two LDO regulators which use internal
PMOS transistors as the pass devices. LDO2 features ultra
low noise that typically does not exceed 30μV RMS to aid
VCO stability. The EN_LDO pin controls LDO1 and LDO2
outputs. The ISL6413 also integrates a RESET function,
eliminating the need for an additional RESET IC usually
required in WLAN applications. This function asserts a
RESET signal whenever the VIN supply voltage drops below
a preset threshold, keeping it asserted for at least 25ms after
VIN has risen above the reset threshold. The PG_LDO
output indicates loss of regulation on either of the two LDO
outputs. Additional features include over current protection
for all three outputs and thermal shutdown.
High integration , excellent efficiency and the thin, Quad Flat
No-lead (QFN) package makes the ISL6413 an ideal choice
to power many of today’s small form factor industry standard
wireless cards such as PCMCIA, mini-PCI and Cardbus-32.
ISL6413 Reference Design
The ISL6413 evaluation board highlights the operation of the
IC in an embedded application.
Power and Load Connections
There are 2 sets of terminals that are used for supplying the
input power and 3 sets of terminals used for loading the 3
outputs (1 PWM and 2 Linear regulators).
Input Voltage - Connect the positive lead of the power
supply to V IN (P1) post and V IN _LDO (P11) post and the
ground lead of the supply to the PGND (P2) post and the
GND_LDO (P10) post.
Output Loading, Sourcing Current - To load the PWM
output, connect the positive lead of the electronic load to the
V OUT (P6) post and the return terminal of the same load
channel to the PGND (P7) post. Similarly, connect the
positive terminal of the second load channel to the
V OUT1 (P9) post and the return terminal to the GND_LDO
(P12) post to load the output of LDO1. The ultra low noise
LDO2 output can be loaded by connecting the positive
terminal of a third channel of the electronic load to the
V OUT2 (P8) post and the return terminal to the GND_LDO
(P12) post.
Startup
There are two distinct start up methods for the ISL6413. The
first method is by the application of power to the inputs of the
IC. A controlled turn on of the outputs is allowed by the soft-
start feature of the IC. The soft start duration for the PWM is
TABLE 1. EVALUATION BOARDS
BOARD NAME IC
PACKAGE
typically 5.5ms with 750kHz switching frequency. The soft-
start duration for LDOs is 120μs.
ISL6413EVAL1
ISL6413IR
24 Ld QFN
1
1-888-INTERSIL or 321-724-7143
|
Intersil (and design) is a registered trademark of Intersil Americas Inc.
Copyright ? Intersil Americas Inc. 2003. All Rights Reserved
All other trademarks mentioned are the property of their respective owners.
